Schedule 1 To Schedule 7
The seven DAILY SCHEDULES all have a standard format allowing the user to select up to 8 schedule changes
per day. The following example shows the standard format for all seven of the daily schedules.
DAILY SCHEDULE hh:mm:ss
NUMBER SCHED TIME GROUP
1 XX:XX AM G1
2 XX:XX AM G2
3 XX:XX AM G3
4 XX:XX AM G4
5 XX:XX AM G3
6 XX:XX AM G2
7 XX:XX AM G1
8 XX:XX AM G1
Daily Schedule 1 Screen
