97
The following table lists the various parameters displayed on the screen.
PARAMETER DEFINITION
VILTER, INC. The name and version number of the installed software.
RECIP COMP. VO.XX
BUILD DATE The date the system was last built.
INIT DATE The date the system was intiaited.
RESET DATE The date and time the system was last reset.
CURNT TIME The current date and time for this panel.
OPTIONS The status of various options are shown on the lower section of the screen.
TIMER STATUS The number of timers currently being used, the total number of available timers,
and the maximum number of timers used since the last reset.
View Discrete I/O
The View Discrete I/O screens are information screens used for viewing purposes only as shown in the following
example.
NOTE: The I/O channels are used for optional equipment.
System Information Definitions
Discrete I/O Rack 1A Screen
