Current System State
The left-most highlighted status banner section displays the CURRENT STATE of the system. The following is a
table with a brief description of possible system states.
CURRENT STATE DESCRIPTION
ACYCLE XX:XX Anti-cycle count down timer has been activated to delay motor start. XX:XX is the time remaining.
STOPPED Compressor is stopped.
STARTING Starting sequence is in progress.
RUNNING Compressor is running.
INCREASING Capacity is increasing.
DECREASING Capacity is decreasing.
LIMIT:CAP Loading was stopped due to capacity
LIMIT:DP Loading was stopped due to high discharge pressure.
UNLOAD:DP Forced unloading due to high discharge pressure.
STOPPING Stopping sequence is in progress.
FAILED Compressor has failed.
RESET The Viltech has been reset.
STOP-OFFLINE Compressor is stopped and is off-line (not available for auto start).
STOP-ONLINE Compressor is stopped and is on-line (available for auto start)
STOP CUT-OUT Compressor is stopped on cut-out pressure (or temperature)
RUN-TRIM The compressor is running in Sequenced mode as the Trim machine.
FULL-LOAD The compressor is running in Sequenced mode as a Fully Loaded machine.
Mode Area
The middle highlighted status banner section displays the general operating mode of the system as shown in the
following table:
MODE DESCRIPTION
AUTO Automatic mode is selected.
MAN Manual mode is selected.
RMT Remote mode is selected.
SEQ Sequenced mode is selected.
