70
TERM DEFINITION
ACTIVE GROUP There are four possible process temperature control groups, each with it’s own
temperature control parameters. This field is used to manually select the active
setpoints group.
High Process Temperature Setpoints
The HIGH PROCESS TEMPERATURE SETPOINTS screen is only visible when the Process Temperature
Control option is enabled.
TERM DEFINITION RANGE
HIGH FAILURE A failure is reported and the compressor is shutdown when
the Process Temperature rises above the High Failure setpoint -58: 122 DEGF
HIGH ALARM An alarm is reported when the Process Temperature rises
above the High Alarm setpoint. -58: 122 DEGF
Process Temperature Active Group Control Definitions
Process Temperature Active Group Control Screen
High Process Temperature Setpoints Screen
High Process Temperature Setpoint Definitions
