67
Temperature Setpoints
The TEMPERATURE SETPOINTS menu allows the user to set temperature related setpoints
described in the following sections.Discharge Temperature Setpoints
Discharge Temperature Setpoints
The DISCHARGE TEMPERATURE SETPOINTS screen allows the operator to set acceptable
ranges for the RECIP discharge temperature
and second discharge temperature (DT2) for 12 &
16 single stage compressors.
.
The following table lists the data entry fields and a description of their purposes.
TERM DEFINITION RANGE
HIGH FAILURE The compressor is failed (stopped) when
the discharge temperature exceeds this value. 32 - 392 DEGF
Discharge Temperature Setpoints Screen
Discharge Temperature Definitions
