Static Sensor Calibration
STATIC SENSOR CALIBRATION is described more fully on page 87 of this chapter.
STATIC CALIBRATION hh:mm:ss
CH NAME MIN MAX
1 SUCTION PRESS XXX.X XXX.X PSIA
2 DISCHARGE PRESS XXX.X XXX.X PSIG
3 OIL PRESS XXX.X XXX.X PSIA
4 DISCHARGE TEMP XXX.X XXX.X DEGF
5 OIL TEMP XXX.X XXX.X DEGF
6 SUCTION TEMP XXX.X XXX.X DEGF
7 PRESS2 OPTIONAL XXX.X XXX.X PSIG
8 PROCESS TEMP XXX.X XXX.X DEGF
SPAN CORRECTION 0.0
OFFSET CORRECTION 0.0
The following table lists the data entry fields and a description of their purpose.
TERM DEFINITION
CH The discrete channel number
NAME The name of the discrete signal.
VALUE Current dynamic value of the discrete signal.
UNIT The unit of measurement for the discrete signal value.
Static Calibration Sensors Screen
Static Calibration Definitions
To Next Page
