7
Fig. 7.B INPUTS WIRING FOR 3-WIRE TRANSMITTER
Shield
3
1
11
7
PWR
+
Out
TX
GND
Fig. 7.C INPUTS WIRING FOR 4-WIRE TRANSMITTER
NOTESNOTES
NOTESNOTES
NOTES:
1) Don’t run input wires together with power cables.
2) Pay attention to the line resistance; a high line resistance
may cause measurement errors.
3) When shielded cable is used, it should be grounded at one
side only to avoid ground loop currents.
4) The input impedance is lower than 5 Ω (20 mA input)
Shield
3
1
11
7
PWR
+
Out
+
TX
PWR
_
Out
_
XKP-1-D1.pmd 25/05/2006, 11.287
