62
CnF. 6CnF. 6
CnF. 6CnF. 6
CnF. 6
- Resolution of the deviation bargraph - [C.I05]- Resolution of the deviation bargraph - [C.I05]
- Resolution of the deviation bargraph - [C.I05]- Resolution of the deviation bargraph - [C.I05]
- Resolution of the deviation bargraph - [C.I05]
This parameter will be available only for MKP models when
“G.brG” [C.I01] is equal to “DEV.”.
Range: 1-2-5-10-20 or 50 = Digits per segment
- Operative set point alignment at start up- Operative set point alignment at start up
- Operative set point alignment at start up- Operative set point alignment at start up
- Operative set point alignment at start up
- [C.I06]- [C.I06]
- [C.I06]- [C.I06]
- [C.I06]
Range:ALG = At start up the operative set point is aligned to
measured value and then it will reach the
selected set point with the programmed ramp
(“Grd1” [r.E14] and “Grd2” [r.E15]).
n.ALG= At start up the operative set point is equal to
the selected set point
NOTESNOTES
NOTESNOTES
NOTES:
1) The “ALG” selection has no effect when the measure is in
error condition.
2) If instrument shutdown has been made during program
execution, the SP.AL parameter has no effect and the
instrument behaviour is related only to the selection of St.Pr
(program restart after power failure [C.G07]) parameter.
- Set point display type - [C.I07]- Set point display type - [C.I07]
- Set point display type - [C.I07]- Set point display type - [C.I07]
- Set point display type - [C.I07]
This selection has effect only when the instrument operates as
controller.
Range: Fn.SP= When device is in normal display mode and it
is performing a set point ramp, the middle
display will show the final set point value.
OP.SP=When device is in normal display mode and it
is performing a set point ramp, the middle
display will show the operative set point value.
XKP-1-D1.pmd 25/05/2006, 11.2862
