NOTE: at the end of the security code setting procedure, set
V101 according to the desired operative mode (see
"Operative mode and hardware lock" paragraph).
RUN TIME AND CONFIGURATION MODESRUN TIME AND CONFIGURATION MODES
RUN TIME AND CONFIGURATION MODESRUN TIME AND CONFIGURATION MODES
RUN TIME AND CONFIGURATION MODES
The hardware selection described in "Operative mode and
hardware lock" paragraph allows you to start one of the
following operative modes:
- configuration mode.
- run time mode
The run time mode can be divided as follows:
- Run time mode as controller
- Run time mode as programmer
At power up, the instrument starts in the same mode (configu-
ration or run time) it was prior to the power OFF.
General note about graphic symbols used for mnemonicGeneral note about graphic symbols used for mnemonic
General note about graphic symbols used for mnemonicGeneral note about graphic symbols used for mnemonic
General note about graphic symbols used for mnemonic
code visualization.code visualization.
code visualization.code visualization.
code visualization.
The instrument displays some characters with special symbols.
The following table shows the correspondence between the
symbols and the characters
symbol character symbol character
"
"k ""W
"
"m ""Z
" "V ""J
