106
Flashes when alarm 2 is in alarm state and it is not
acknowledged.
3 Lit when OUT 3 is used as control output and it is in ON
condition or when servomotor output increases or when
Event 3 is activated or when alarm 3 is in alarm state and
acknowledged.
Flashes when alarm 3 is in alarm state and it is not
acknowledged.
4 Lit when OUT 4 is used as control output and it is in ON
condition or when servomotor output decreases or when
Event 4 is activated or when alarm 4 is in alarm state and
acknowledged.
Flashes when alarm 4 is in alarm state and it is not
acknowledged.
IN 1 to IN 4 Lit when the related digital input is in ON
condition.
OUT 10 to OUT 19 Lit when the related digital output is in ON
condition.
DISPLAY FUNCTION DISPLAY FUNCTION
DISPLAY FUNCTION DISPLAY FUNCTION
DISPLAY FUNCTION
DURING PROGRAMMER MODEDURING PROGRAMMER MODE
DURING PROGRAMMER MODEDURING PROGRAMMER MODE
DURING PROGRAMMER MODE
When device operates in programmer mode and a programWhen device operates in programmer mode and a program
When device operates in programmer mode and a programWhen device operates in programmer mode and a program
When device operates in programmer mode and a program
is running.is running.
is running.is running.
is running.
The upper display shows the process variable (the value will be
flashing if device is in WAIT mode) and RUN, PRG and SEG
indicators are lit.
We define the above condition as “programmer normal display
mode”.
The ,  and  indicators lit if the segment in progress is a
ramp down, a soak or a ramp up respectively.
When a program starts, the middle display shows:
- the operative set point value, if the segment is a ramp
- the remaining time to end the segment, if the segment is a
soak.
NOTE:NOTE:
NOTE:NOTE:
NOTE: if the remaining time is more than 1 hour, it will be
shown in hours and minutes, if, the remaining time is less
than 1 hour, it will be shown in minutes and seconds.
The lower display shows the running program number on the
two most significant digits (MSD) and the number of the
segment in progress on the two LSD; the decimal point at the
left of the 2 LSD lit.
Pushing FUNC pushbutton it is possible to change the
information on the middle and lower displays.
The first FUNC pushbutton pressure modify the middle display
