ero electronic MKP - OFD (Output Failure Detection) Alarm Configuration; OFD (Output Failure Detection) Alarm Action; Group 6 Default Data Loading

94
Gr. 7Gr. 7 Gr. 7Gr. 7
Gr. 7
the alarm threshold plus or minus hysteresis. If the alarm is
programmed as a process alarm or control output alarm, this
function masks the alarm condition at instrument start-up
until process variable reaches the alarm threshold plus or
minus hysteresis.
2) The change from On to OFF has immediate effect, while the
change from OFF to On has effect at the next start up or set
point change
- OFD (Output Failure Detection) alarm - OFD (Output Failure Detection) alarm
- OFD (Output Failure Detection) alarm - OFD (Output Failure Detection) alarm
- OFD (Output Failure Detection) alarm
configuration - [r.F17]configuration - [r.F17]
configuration - [r.F17]configuration - [r.F17]
configuration - [r.F17]
This parameter is available only when OFD option is configured
(“Fd.Fn” [C.I11] is different from "nOnE").
Range:A. = Alarm with automatic reset
A.Ac = Alarm with automatic reset and acknowledge
L. = Alarm with manual reset
NOTENOTE
NOTENOTE
NOTE: When alarm configuration has been changed, the alarm
status will be deleted.
- OFD (Output Failure Detection) alarm action- OFD (Output Failure Detection) alarm action
- OFD (Output Failure Detection) alarm action- OFD (Output Failure Detection) alarm action
- OFD (Output Failure Detection) alarm action
- [r.F18]- [r.F18]
- [r.F18]- [r.F18]
- [r.F18]
This parameter is available only when one output is configured
as OFD alarm annunciator (“Fd.Fn” [C.I11] and “Fd.Ou” [C.I13]
are different from “nonE”).
Range: dir = direct action (Relay energized or SSr=1 in
alarm condition)
rEV = Reverse action (Relay energized or SSr=1 in
non alarm condition)
NOTENOTE
NOTENOTE
NOTE: When OFD output is in OR condition with an alarm or
an event output, the “Fd.Ac” parameter can only be monitored
but not modified and it assumes the same action defined (by
“Alarm Action” or “Event Logic Level”) for the alarm or the
event.
- Group 6 default data loading - [r.F19] - Group 6 default data loading - [r.F19]
- Group 6 default data loading - [r.F19] - Group 6 default data loading - [r.F19]
- Group 6 default data loading - [r.F19]
Range: OFF = No loading data
ON = Loading data
Gr. 6Gr. 6 Gr. 6Gr. 6
Gr. 6
