ero electronic MKP - Alarm 2 Action; Alarm 2 Stand by (Mask) Function; Alarm 3 Type

To Next Page

To Previous Page

Gr. 6Gr. 6

Gr. 6

- Alarm 2 action - [r.F07]- Alarm 2 action - [r.F07]

- Alarm 2 action - [r.F07]

This parameter is available only when OUT 2 is configured as

alarm 2 output (“O2.Fn” [C.E02] = “ALr.2”)

Range: dir = direct action (Relay energized or SSr=1 in

alarm condition)

rEV = Reverse action (Relay energized or SSr=1 in

non alarm condition)

- Alarm 2 stand by (mask) function - [r.F08]- Alarm 2 stand by (mask) function - [r.F08]

- Alarm 2 stand by (mask) function - [r.F08]

This parameter is available only when OUT 2 is configured as

alarm 2 output (“O2.Fn” [C.E02] = “ALr.2”)

Range: OFF = Stand-by function disabled

On = Stand-by function enabled

NOTESNOTES

NOTES:

1) If the alarm is programmed as band or deviation alarm, this

function masks the alarm condition after a set point change

or at the instrument start-up until process variable reaches

the alarm threshold plus or minus hysteresis. If the alarm is

programmed as a process alarm or control output alarm, this

function masks the alarm condition at instrument start-up

until process variable reaches the alarm threshold plus or

minus hysteresis.

2) The change from On to OFF has immediate effect, while the

change from OFF to On has effect at the next start up or set

point change

- Alarm 3 type - [r.F09]- Alarm 3 type - [r.F09]

- Alarm 3 type - [r.F09]

This parameter is available only when OUT 3 is configured as

alarm 3 output (“O3.Fn” [C.E03] = “ALr.3”)

Range:Proc = Alarm on process variable

bAnd = Band alarm on process variable

dEV = Deviation alarm on process variable

ñAin = Alarm on Main control output value

SECn= Alarm on Secondary control output value

NOTENOTE

NOTE: When alarm type has been changed the alarm

threshold will be forced to its default value and alarm status will

be cleared.

XKP-1-D1.pmd 25/05/2006, 11.2891
