Gr. 5Gr. 5

Gr. 5

- Set point high limit - [r.E13]- Set point high limit - [r.E13]

- Set point high limit - [r.E13]

Range: from rL [r.E12] to “ñ.In.H” [C.d06].

NOTESNOTES

NOTES: Whenever “ñ.In.H” [C.d06] has been modified, the

following occurs:

1) rH will be realigned to it;

2) if the set point values are out of the new limits, "rH"

automatically assumes the default value.

- Rate of change for positive set point- Rate of change for positive set point

- Rate of change for positive set point

variations - [r.E14]variations - [r.E14]

variations - [r.E14]

Range: from 1 to 200 digits per minute.

Above this value the display shows “Inf” and the transfer will be

a step change.

- Rate of change for negative set point- Rate of change for negative set point

- Rate of change for negative set point

variations - [r.E15]variations - [r.E15]

variations - [r.E15]

Range: from 1 to 200 digits per minutes.

Above this value the display shows “Inf” and the transfer will be

a step change.

will be ignored and the output will step up to the value set by

“Añ.UL” [C.G04] parameter.

- Secondary output cycle time - [r.E11]- Secondary output cycle time - [r.E11]

- Secondary output cycle time - [r.E11]

This parameter is available when a time proportional secondary

control output is configured.

Range: from 1 to 200 s

- Set point low limit - [r.E12] - Set point low limit - [r.E12]

- Set point low limit - [r.E12]

Range: From “ñ.In.L” [C.d05] to rH [r.E13].

NOTESNOTES

NOTES: Whenever “ñ.In.L” [C.d05] has been modified, the

following occurs:

1) rL will be realigned to it;

2) if the set point values are out of the new limits, "rL"

automatically assumes the default value.
