ero electronic MKP - OUT 5 Function; OUT 5 Range; OUT 5 Retransmission Initial Scale Value; Valve Position Indication

38
CnF. 2CnF. 2 CnF. 2CnF. 2
CnF. 2
- Valve position indication - [C.E06]- Valve position indication - [C.E06]
- Valve position indication - [C.E06]- Valve position indication - [C.E06]
- Valve position indication - [C.E06]
This parameter will be displayed only when open loop
servomotor control drive output is configured.
Range:Fb = The valve position is measured and displayed
no.Fb = The valve position is not measured
NOTENOTE
NOTENOTE
NOTE: If the feedback option is not mounted, this parameter
will be forced to “no.Fb” (no feedback).
- OUT 5 function - [C.E07]- OUT 5 function - [C.E07]
- OUT 5 function - [C.E07]- OUT 5 function - [C.E07]
- OUT 5 function - [C.E07]
Range:nonE =Output not used
ñAin =Main control output (linear)
SECn =Secondary control output (linear)
PV.rt =Process variable retransmission
SP.rt =Operative set point retransmission
NOTENOTE
NOTENOTE
NOTE: When the option circuitry is not mounted the middle
display will show “no.Pr” (not present).
- OUT 5 range - [C.E08]- OUT 5 range - [C.E08]
- OUT 5 range - [C.E08]- OUT 5 range - [C.E08]
- OUT 5 range - [C.E08]
This parameter will be available only when Out 5 is configured
("O5.Fn" [C.E07] different from "nonE")
Range:0-20 = 0÷20 mA
4-20 = 4÷20 mA
- OUT 5 retransmission initial scale value- OUT 5 retransmission initial scale value
- OUT 5 retransmission initial scale value- OUT 5 retransmission initial scale value
- OUT 5 retransmission initial scale value
- [C.E09]- [C.E09]
- [C.E09]- [C.E09]
- [C.E09]
This parameter will be available only when Out 5 function
[C.E07] is configured as “PV.rt” or “SP.rt”
Range:From -1999 to 9999
NOTESNOTES
NOTESNOTES
NOTES:
1) Decimal point is positioned as previously selected at “CnF.1
- ñ.In.d” [C.d03])
2) The OUT 5 retransmission initial scale value can be higher
than OUT 5 retransmission full scale value [C.E.10].
