133
0.0 % to 99.9 % or a value within the scale configured by
“ñC.E.L” [C.F09] and “ñC.E.H” [C.F10] when a scaled
readout is applied to the main output.
The instrument will show “ . “ when the control output
is > 100.0 %.
NOTENOTE
NOTENOTE
NOTE: When the MAIN output is a servomotor type, the
instrument shows, for this output, the feedback position (in
the range from -19.0 % to 99.9 %) instead of the output in
percent.
f) Push FUNC push-button again, the lower display will show
"S." followed by the SECONDARY control output value in the
range 0.0 % to 99.9 % or within the scale configured by
“SC.E.L” [C.F15] and “SC.E.H” [C.F16].
The instrument will show “ . “ when the control output
is > 100.0 %.
NOTENOTE
NOTENOTE
NOTE: When the secondary output is a servomotor type, the
instrument shows, for this output, the feedback position (in
the range from -19.0 % to 99.9 %) instead of the output in
percent.
g)Push FUNC push-button again, the lower display will show
the value of the auxiliary input, if configured.
- Pushing FUNC push-button again, the display will come
back to the control output value indication.
All the seven types of visualization are not bound to a time out
unless OFD (output failure detection) is in the not acknowl-
edged alarm condition.
In this situation, the instrument forces the indication described
at point d) and, if a different indication is required, it restores
this indication after time out (see “t.out” [C.I10]).
NOTESNOTES
NOTESNOTES
NOTES:
1) The previous informations will be displayed only if the
related function has been previously configured.
2) After parameter modification or monitoring, the instrument
comes back to the "normal display mode" with, on the lower
display, the indication previously selected.
XKP-1-D1.pmd 25/05/2006, 11.28133
