Chapter 7: Service and troubleshooting
EST3X Technical Reference Manual 195
Table 54: Annunciator address set
Annunciator Number Address set Annunciator Number Addresses set
1 0290-0296 16 4790-4796
2 0590-0596 17 5090-5096
3 0890-0896 18 5390-5396
4 1190-1196 19 5690-5696
5 1490-1496 20 5990-5996
6 1790-1796 21 6290-6296
7 2090-2096 22 6590-6596
8 2390-2396 23 6890-6896
9 2690-2696 24 7190-7196
10 2990-2996 25 7490-7496
11 3290-3296 26 7790-7796
12 3590-3596 27 8090-8096
13 3890-3896 28 8390-8396
14 4190-4196 29 8690-8696
15 4490-4496 30 8990-8996
Table 55: Local monitor pseudo points
Address
Label Source Description
0615
Incoming Ring 3-MODCOM An incoming call was received
0622
Outgoing Call in
Progress
3-MODCOM The dialer is active
0629
Request Backup 3-ZAxx N/A
0650
All Call Active 3-ASU
(3X-PMI)
An operator pressed the All Call switch
0651
Mic Key Active 3-ASU
(3X-PMI)
An operator pressed the push-to-talk
button on the paging microphone
0673
Mapping In Progress
DataCard_1
3-SSDC
3-SSDC1
3-SDDC
3-SDDC1
The loop controller is currently mapping
the devices in the field
0674
Mapping Disbled Data
Card_1
3-SSDC
3-SSDC1
3-SDDC
3-SDDC1
Mapping was manually disabled
