Euphonix Max Air Mixing Console Operation Manual Busses
111
Figure 6-2 Group Bus View
The letters on the left of Figure 6-1 denote the 16 Main sections. The letters I, L, M, N,
and O have been omitted to avoid being confused with one another. Touch the cell to
the right of the letter to name the section.
The Main sections are the main mix outputs of the console. A Main section consists of
one or more Main busses. There are 24 busses available.
6.2.1 Format Selector
To set the pan format for a Main section:
1. Select the busses to configure.
2. Touch the right arrow in the Format Selector to scroll through the formats.
Touch the left arrow to scroll backwards.
