Euphonix Max Air Mixing Console Operation Manual Touchscreen
70
4.6.2 *Knobset
Select the *Knobset tab from the System View. The *Knobset View allows a custom-
ized set of 16 knob parameters to be displayed on the Strip when the channel’s * key is
pressed at the top of the Strip.
Figure 4-26 *Knobset View
1. Select the page (1 in Figure 4-26) and knob position (2) for the function param-
eter from the Custom (*) Knobset area on the left.
2. Select a Function from the center of the View (3).
3. Select the parameter from the Function Parameters section on the right (4).
4. Repeat for each of the four knob positions and pages.
The Fader button can be used to put the Swap channel’s fader on a knob. This can pro-
vide simultaneous control of the Main and Swap fader level controls.
1
2
3
4
