Euphonix Max Air Mixing Console Operation Manual Quickstart to Common Tasks
29
5. Select Hub1-2 and touch Rename Port. Type Analog 1-24.
6. Select Hub1-3 and touch Rename Port. Type Digital In 1.
7. Select Hub1-4 and touch Rename Port. Type Digital In 2.
8. If any of the MADI inputs are not connected, rename them UNUSED. Use the
keyboard commands <Ctrl-C> and <Ctrl-V> to copy and paste UNUSED to
save time.
NOTE: Systems with a SH612 Studio Hub will display additional ports.
3.2.2 Assigning the Mic Preamps to Hubs
In the above example the first MADI input port is used for the Mic Preamps. The patch
system must be informed which MADI input each ML530 (24-Channel Mic Pre) con-
nects to so their input controls appear on the corresponding input channel knobset.
1. In the Patch view, select the Cabling tab.
2. Select MADI Out Ports from the list on the left.
These refer to the MADI output of external mic preamps, each with 24 chan-
nels. In our example, we only have one.
3. Select the green MADI Out box next to Mic1 Port.
It is displayed in the Sources list on the right.
4. Select MADI In Ports from the list on the left.
5. Select the blue MADI In box next to Hub1-1.
It is displayed in the Destinations list on the right.
6. Touch Patch Selected to make the connection.
The console now knows how the mic/line interface is connected so the proper input
controls appear at the top of the channels they are connected to.
Because Hub1-1 has been designated as a MADI connection to the Mic/Line interface,
selecting the Hub1-1 sub-category in Sources shows Device Patch in the first 24 cells
and will not allow selection unless they are unpatched.
