6.5.3 Main View
Select the Main View button to display how channels are mapped to the Main busses.
Touch the Strip View or Channel View buttons (1 Figure 6-8) in to display strips and
channels, respectively. Figure 6-8 shows the Main A Channels View.
Select a Main section from the bottom lettered buttons (2) to view channels mapped to
that section. Touch the arrow buttons (3) to display the channels or strips to view.
Figure 6-8 Main View: A-Channels
Touch a bank of 16 knobs to assign them to the Soft Knobs to assign or de-assign a
channel from a Main bus.
1
2
3
