Euphonix Max Air Mixing Console Operation Manua
l
Busses
119
Figure 6-
7
Aux Bus View-Channels
Figure 6-7 shows the pan settings for channels 1–48 routed to aux bus 5/6.
Touch a bank of 16 knobs to assign them to th
e Soft Knobs to edit aux level, pre/post
setting, and in/out.
118
120
