Euphonix Max Air Mixing Console Operation Manual Layouts and Snapshots
158
To modify SS 1:
1. Recall SS 1.
2. Adjust parameters on the desk to the desired settings.
3. Clear SS 1.
4. Select the same channels and functions as stored previously.
5. Store SS 1.
Strip View
Select Strip View to view strips instead of channels (4 in Figure 9-4). Use the Main,
Swap, and Center tabs to select the desired number, level, and type of strips (5).
Figure 9-4 Store Snapshot: Strip View
Use the Select All, Select None, and Select Range buttons (see page 75) to assist your
selection. Touch the Close button to store the Snapshot.
Channel View
Select Channel View to view channels instead of strips (1 in Figure 9-5). Use the 1–
48, 49–96, Grp Masters, and MF Masters tabs to select the desired type of channels
(2). Channels can be selected across tabs. A partially illuminated tab (1–48 in Figure 9-
5) indicates channels are selected there although that is not the active tab.
1
2
3
5
4
