Euphonix Max Air Mixing Console Operation Manual Center Section
135
7.3.1 Talkback
Touch the Talkback tab to display the Talkback section.
Figure 7-12 Talkback/Slate Setup Popup
Monitors
Talkback Mic 1 and Talkback Mic 2 can be routed to Mon A–D by touching the buttons
at the top of the Talkback Setup popup (1 in Figure 7-12). These buttons are momentary
unless the Talkback Button Latch button (4) is lit, in which case they can be toggled
on/off each time they are touched. The Talkback Button Latch button also latches the
four Talkback/Slate keys on the surface (Figure 7-11). More than one monitor can be
active by pressing multiple buttons and all can be active by pressing the Talk to All but-
ton.
When a talkback button is pressed, the monitors receiving talkback and the main control
room speaker are dimmed by the level set for the Dim key (see Dim and Cut on page
131).
Set Talkback Mic 1 and Talkback Mic 2 levels using the faders (2). Talkback Mic 1 and
Mic 2 can be turned on/off by toggling their On buttons.
Aux Busses
The same rules apply to the aux busses as monitors. Select the aux busses (single or
pairs) to route the talkback signals (3). They latch or are momentary based on the Talk-
back Button Latch button.
1
2
3
4
