Euphonix Max Air Mixing Console Operation Manual Center Section
145
7.8 Keypad
The keypad is used to recall Layouts, Snapshots, custom (*) channel strip Knobset pag-
es, trigger Custom events, or recall channels to the Super Channel.
Figure 7-23 CM404 Keypad
Press the Layouts, Snapshots, Knobsets, or Custom keys to recall those respective
functions. That key remains active (lit) until another key is pressed or that key is pressed
again. If none of the four keys are lit, then the keypad assigns a channel to the Super
Channel.
If the One Shot key is off, the keypad acts as a normal numeric keypad. Press the de-
sired number and then press the Enter key. Press Clear to cancel all entered numbers.
The numbers display in the lower-right Keypad area of the Touchscreen.
If One Shot is on, the 1–9 keys immediately recall without pressing Enter. The Key-
pad area of the Touchscreen shows the first nine layouts, snapshots, custom knobset
pages, or Custom key names.
Layouts
SetupOne Shot
CustomSnapshots Knobsets
7
4
1
Clear 0
2
5
8 9
6
3
Enter
