Euphonix Max Air Mixing Console Operation Manual Touchscreen
60
4.3.3 Cabling
This category handles MADI cable connections for the ML530 Mic/Line Interfaces.
Mic/Line Interface Patching
For mic inputs and analog inputs not at +4 dB, the Euphonix ML530 provides 24
preamps each with gain, phantom power, high-pass filter, and hiz/loz switching. The
analog outputs are connected to an AM713 Analog to MADI converter which then con-
nects to one of the MADI inputs.
The patch system must be informed which MADI input each ML530 connects to so
their input controls appear on the corresponding input channel knobset. Note how each
Mic/Line Interface is connected.
In the example that follows, the MADI output from the Analog to MADI converters of
two ML530 Mic/Line interfaces have been connected to the inputs of Hub1-1 and
Hub1-2.
NOTE: We recommend patching each ML530 channel to only one channel input.
