Euphonix Max Air Mixing Console Operation Manual Quickstart to Common Tasks
43
Control Room Monitors
1. Press the Setup button in the Control Room Monitor area of the Super Channel
on the surface.
2. Select the CR Source tab.
3. Select the appropriate source from the screen.
In our example the fifth Main section should be labeled Prog and has the main
program output.
The three buttons labeled Main Spkrs, Alt 1, and Alt 2 allow using three different
speaker sets in the control room.
Monitor A–D
The four speaker sets labeled Mon A–D can be used for additional monitoring includ-
ing green room feeds, floor foldback, etc. Setup is simple: press the Setup button at the
top-right of the Super Channel section to bring up the source options for these monitors.
3.9 Save a Default Title
Once you have completed this setup process, you should save this Title.
1. Touch the File menu button and select the Title tab.
2. Touch the Save button in the Current Title box to save all the changes you
have made. Do this frequently when making changes.
3. If you touch the Save As Default button, the current settings will become the
default settings and will be loaded when a new Title is created.
WARNING: Do not do execute step 3 if your technical or operational department has
already set up the console and saved a Default Title.
