FAAC A1000 User Manual

A1000 105 532210 04 - Rev.A
94
Vp Lt B I C D
700 1500 460 1000 380 2140 800 1700 560 1080 480 2300 900 1900 660 1160 580 2460 1000 2100 760 1240 680 2620 1100 2300 860 1320 780 2780 1200 2500 960 1400 880 2940 1300 2700 1060 1480 980 3100 1400 2900 1160 1560 1080 3260 1500 3100 1260 1640 1180 3420 1600 3300 1360 1720 1280 3580 1700 3500 1460 1800 1380 3740 1800 3700 1560 1880 1480 3900
Vp Lt B I C D
1900 3900 1660 1960 1580 4060 2000 4100 1760 2040 1680 4220 2100 4300 1860 2120 1780 4380 2200 4500 1960 2200 1880 4540 2300 4700 2060 2280 1980 4700 2400 4900 2160 2360 2080 4860 2500 5100 2260 2440 2180 5020 2600 5300 2360 2520 2280 5180 2700 5500 2460 2600 2380 5340 2800 5700 2560 2680 2480 5500 2900 5900 2660 2760 2580 5660 3000 6100 2760 2840 2680 5820
C
I
85
Lt
Vp
B
Translation of the original instructions
ENGLISH
23.2 POSITION OF COMPONENTS ON THE A1000 SUPPORT PROFILE
A1000 WITH RIGHT OPENING SINGLE LEAF
B = Carriage fixing distance on the sliding leaf C = Motor position D = Transmission belt length I = Motor / transmission unit centre distance Lt = Head section length Vp = Free passage opening 100 = leaf overlap (mm)
Lt = Vp X 2 + 100
Motor
Power supply
Return
pulley
Control
board
