FAAC A1000 User Manual

A1000 93 532210 04 - Rev.A
Translation of the original instructions
ENGLISH
OK
OK
OK
200 UC FAILURE
3
ERRORS
201...................221
222 TEST VMAIN
1 ERRORS
2 AUX ERRORS
OK
The display shows current errors:
- 200 UC fault (Corrupted FW or corrupted RAM)
- 201 Aux Mot failure
- 202 High friction
- 203 Aux Mot Driver
- 204 FW Not Compatible
- 205 Motor rotation
- 206 Encoder failure
- 216 Communication
(Communication problem between the 2 boards)
- 217 Incorrect opening position
- 218 Obstacle
- 219 Incorrect ID
- 220 Vmain
- 221 Timeout
- 222 Vmain Test
MENU 4 INDICATIONS
OK
OK
OK
OK
41 TIME LOSS
4
WARNINGS
42.....................74
80 NON STANDARD
PROGRAM.
The display shows current alerts:
- 41 Date and time missing
- 42 Clock battery discharged or missing
- 44 Emergency active
- 45 TIMER active (indicated with T on HOME PAGE)
- 46 Timer function in progress
- 47 Last movement carried out with battery
- 48 Night-time mode operation
- 49 Manual mode operation
- 50 Partial mode operation
- 51 Obstacle during closing
- 52 Obstacle during opening
- 53 Number of maintenance cycles corrupted
- 54 Motor block failure
- 55 Pharmacy mode operation
- 56 Battery operation
- 57 Searching for opening stop
- 58 Searching for closing stop
- 59 Motor block fault (only with monitoring KIT)
- 60 Maintenance request
- 61 SDK EVO / LK EVO
/ KSEVO fault
- 62 Battery charger failure
- 63 Intrusion in progress
- 65 SETUP in progress
- 67 Battery saving
- 68 Safety devices test failed
- 69 Semi-automatic input keeps door open
- 70 Battery charge level
- 71 Slave Intercom
- 72 CANBUS Failure
- 73 Intercom Node Alarm
- 74 INTERLOCK operating mode active
- 80 Programming other than standard
MENU 5 CYCLE COUNTER
OK
OK
OK
OK
5
CYCLES COUNT
CYCLES RESET
MAINTENANCE
CYCLES NUMBER
■
1 Number of cycles
The display shows the number of cycles performed:
- ABSOLUTE counter not resettable
- RELATIVE counter resettable (with CYCLE RESET)
■
2 Maintenance
To set the deadlines for maintenance request:
- DATA (default: disabled) 00/00/00
- number of cycles minimum: 1000; maximum 1000000

Entering a date is optional.
■
3 RESET CYCLES
It resets RELATIVE cycle counter to zero. This command requires
confirmation

The ABSOLUTE cycle counter cannot be reset to zero.
MENU 6 DATE / TIME
OK
OK
OK
OK
SET DATE
6
DATE/TIME
SET TIME
DAYLIGHT SAV TIME
■
SET DATE
Set date in dd/mm/yy.
■
SET TIME
Set time in HH:mm.
■
EUROPEAN DAYLIGHT SAVING TIME
European daylight saving time is enabled by default.
Available options are:
