FAAC A1000 User Manual

A1000 94 532210 04 - Rev.A
Translation of the original instructions
ENGLISH
- Enabled
- Disabled
MENU 7 TIMER
OK
OK
OK
OK
OK
OK
7
OK
OK
OK
TIMER
MON-SUN
JOLLY SLOTS
SUNDAY
JOLLY
TUESDAY./.FRIDAY
MONDAY
TIMER STATE
MON-FRI
When TIMER is on:
- alert T appears on the HOME PAGE 80
- the door operating mode is set automatically based on pro-
grammed time bands
- the timer must be disabled to manually change the operating
mode activated by it
Programming requires:
- setting time bands for each day of the week or by groups of days.
There are up to 6 time bands for each day
- assign an operation mode to each time band
- set any JOLLY
■
1 Timer status
Enables/disables timer function:
- ENABLED
- DISABLED
Default CF1 CF2 CF2 CF4 CF5
■
Timer status Disabled
When the TIMER is disabled programming is stored.
■
2Monday 8 Sunday
To program the days of the week:
1. Select the day.
2. Select the time band.
MONDAY
ESC ↑ ↓ OK
- > BAND1
- BAND2
- BAND3
- BAND4
3. Assign an operating mode to the time band:
- 0 No function
- 1 Auto Twodir Total
- 2 Auto Out Total
- 3 Auto Twodir Partial
- 4 Auto Out Partial
- 5 Open Total
- 6 Open Partial
- 7 Auto In Total
- 8 Auto In Partial
- 9 Night-time
- 10 Partial night-time
- 11 Interlock
- 12 Interlock EXIT Only
- 13 Interlock Entry Only
4. Set time band start and end time.
BAND 1
ESC ↑ ↓ OK
START 00:00
END 00:00
5. Proceed in the same way for the other desired time bands.
6. In Auto Twodir Total mode, an example:
- BAND 1 08:00-08:59 Open Total
- BAND 2 09:00-09:59 Open Partial
- BAND 3 11:00-11:59 Auto Out Total
- BAND 4 12:00-12:01 Auto Out Partial
- BAND 5 17:59-16:30 Auto Twodir Partial
- BAND 6 22:00-23:59 Auto Twodir Total
■
9 Mon-Sun; 10 Mon-Fri
To quickly program groups of days of the week with the same time
bands:
1. Select the group of days (from Mon-Sun or from Mon-Fri).
2. Select the time band.
3. Set time band start and end time.
4. Assign the operating mode to the time band. Repeat stages from
2 to 4 for any other time bands.
5. Apply programming to the group of days by selecting APPLY.

Confirm APPLY to apply the time bands to the set group days, any pre-
existing programming on individual days is overwritten.
■
11 Wild Card
To PROGRAM TIMER operation in Wild Card intervals (one or more
days that require different programming):
1. Select the Wild Card time band.
