A1000 8 532210 04 - Rev.A
Translation of the original instructions
ENGLISH
1.2 MEANING OF THE SYMBOLS USED
!
Perform the operations and steps described in compliance with safety
regulations and the instructions provided so as to prevent the risks indi-
cated by the symbols in the following tables.
2 Symbols: tools (type and size)
6-8...
HEX WRENCH of the specified size (6, 8...)
6-8...
ALLEN KEY with ROUND HEAD of the specified size (6, 8...)
CIRCLIP PLIERS
6-8...
FLAT-HEAD SCREWDRIVER of the specified size (6, 8...)
6-8...
CROSS-HEAD SCREWDRIVER of the specified size (6, 8...)
6-8...
METAL DRILL BITS of the specified size (6, 8...)
6-8...
MASONRY DRILL BITS of the specified size (6, 8...)
LEVEL
45°...
COUNTERSINK with specified angle (45°...)
M6-M8...
THREADING TAP with specified thread (M6, M8...)
ROUND SAW
GLASS SUCTION CUPS
PALLET FORKS
TOOL with TORQUE ADJUSTMENT
It indicates that a tool with torque adjustment is required where necessary
for safety reasons.
TIGHTENING TORQUE VALUE
The torque wrench and the tightening torque in Nm is specified in the
figures. E.g.: HEX WRENCH 6 set at 2.5 Nm
2.5
2.5
Nm
1 Symbols: notes and warnings on the instructions
!
WARNING
It indicates the risk of personal injury or damage to parts. The described
operation/step must be carried out in compliance with the instructions
provided and with safety regulations.
F
WARNING ELECTRIC SHOCK HAZARD
Indicates risk of electrocution. The described operation/step must be
carried out in compliance with the instructions provided and with safety
regulations.
WARNING
Details and specifications to be followed with the utmost attention, in
order to ensure correct operation of the system.
PAGE REFERENCE
It refers to the page indicated by the number for details or clarifications.
PICTURE REFERENCE
It refers to the picture indicated by the number.
TABLE REFERENCE
It refers to the table indicated by the number.
Li
WARNING
The batteries and electronic components must not be disposed of with
household waste but delivered to authorised disposal and recycling
centres.
