A1000 13 532210 04 - Rev.A
Translation of the original instructions
ENGLISH
2.5 TYPES OF SYSTEM SUPPLIED
The FAAC A1000 series automations may be supplied as follows:
- Automation kit: A1000 KIT
- Assembled automation: A1000 PA
- Complete entry door: A1000 CS
INSTALLATION ACCORDING TO THE TYPE OF SYSTEM
SUPPLIED
!
During installation, it is recommended to comply with the order of the
sections set out based on the type of purchased supply.
A1000 KIT
A
B
A. Pack containing automation components to be assembled on the
FAAC support profile.
B. Pack with FAAC profiles purchased in 4.30 m or 6.10 m long bars.
Sequence of installation phases (dedicated sections in the instructions
manual)
- Inspection and preparation (§ 3)
- Cutting the profiles (§ 5)
- Installation of the head section: assembly of the components on the
support profile (use exclusively FAAC profiles) (§ 6)
- Installation of the head section (§ 8)
- Installation of the leaves (§ 9) - for glass leaves see (§ 10)
- Electronics installation (§ 12)
- Startup (§ 13)
A1000 PA
C
C. Automation assembled on FAAC* head section.
Sequence of installation phases (dedicated sections in the instructions
manual)
- Inspection and preparation (§ 3)
- Installation of the head section (§ 8)
- Installation of the leaves (§ 9) - for glass leaves see (§ 10)
- Electronics installation (§ 12)
- Startup (§ 13)
A1000 CS
C
D
E
C. Automation assembled on FAAC* head section.
D. FAAC leaves (with TK20 or TK50 profiles)
E. Package with TK20 or TK50 profiles for installing the FAAC door
wall frame.
Sequence of installation phases (dedicated sections in the instructions
manual)
- Inspection and preparation (§ 3)
- Installation of the door wall frame (§ 8) with FAAC - TK50 or TK20
profiles.
- Installation of the head section (§ 8)
- Installation of the leaves (§ 9) - for glass leaves see (§ 10)
- Electronics installation (§ 12)
- Startup (§ 13)
* supplied with the required measurement and with pre-assembled
automation components.
