FAAC A1000 User Manual

A1000 14 532210 04 - Rev.A
Translation of the original instructions
ENGLISH
A1000 AUTOMATION COMPONENTS
Support profile
It lets you adequately fasten the automation along a load-bearing metal
or masonry wall.
FRONT CASING CLOSING PROFILE
Aluminium profile for front head section closure.
H100 version available.
Plates with screws
Accessories for installation of components.
Motor with encoder
Return pulley
Leaf Support/Sliding Carriages - (2 for each leaf)
Transmission belt
!
It is compulsory to use the FAAC belt for the A1000
Control electronics module
0.0
RESET/SETUP
DL2
DL11
MAIN
F1
USB
+
- F
ERR
BAT1
OPEN
EMERG
BAT2
SIC
_
OP
SIC
_
CL
J10
J14
J11
J12
J13
V G
S1
G
T
J1
J17
V RX TX G
J8
E1 G E2
J7
T1 G
T2
R1
G R2
J9
V G 01 02 02
J22
J21
V
G
I1
I2
G
I3
I4
V
J18
G CH CL G
J23J24
J25
V G
S2
G
T
J2
E1SL electronic board and power supply unit.
