FAAC A1000 User Manual

A1000 48 532210 04 - Rev.A
MAIN
F1
J10
J14
J11
J12
J12
J11
DL11
J13
V G
S1
G
T
J1
V RX TX G
J8
E1 G E2
J7
T1 G
T2
R1
G R2
J9
V G 01 02 02
J22
J21
V
G
I1
I2
G
I3
I4
V
J18
G CH CL G
V G
S2
G
T
J2
J13
59
60
ABC
   
J13
2
1
2
3
4
5
C
B
A
Translation of the original instructions
ENGLISH
12.3 MOTOR AND ENCODER
1. Connect motor M1 to connector J11.
2. Connect the encoder cable of motor M1 to connector J12. 59
!
WARNING: TESTS THE ENCODER CONNECTION BEFORE MOVEMENT
12.4 XB LOCK MOTOR BLOCK AND
MONITORING OPTIONAL
!
ALWAYS DISCONNECT the power supply and disconnect the emergency
battery before connecting or disconnecting the motor block in order to
avoid damaging the device.
1. Connect the motor release monitor (IF INSTALLED) to the release
terminal block 60-C.
2. Connect the motor block to the control board using the wired
connector 60-

.
3. Program the motor block operation (
EL
EL) and enable monitoring
(
SU
SU) (IF INSTALLED).
A
no
no= XB LOCK motor block disabled.
1
1 = XB LOCK motor block closed in NIGHT-TIME mode
2
2 = XB LOCK motor block closed in NIGHT-TIME and
ONE-DIRECTIONAL mode.
3
3 = XB LOCK motor block closed in NIGHT-TIME mode
and with leaves open
4
4 = XB LOCK motor block closed at the end of each
movement.
Manual release microswitch
C
SU
SU=
Y
Y (monitoring enabled - IF INSTALLED)

If the motor block malfunctions, the system signals ERROR 26 on the
display and on SDK EVO.
If there is a power failure, the position of the motor block remains un-
changed. The motor block is always open in manual mode.
1
green
C
Motor block monitoring
(IF INSTALLED)
2
pink
B Manual release microswitch
3
yellow
4
white
A Motor block coil
5
brown
1
2
3
2
B
