A1000 12 532210 04 - Rev.A
Translation of the original instructions
ENGLISH
2.4 TECHNICAL SPECIFICATIONS A1000
7 Technical specifications
MODEL A1000 single leaf A1000 double leaf
Length * [mm] from 1500 to 6100 from 1700 to 6100
Depth * [mm] 150 150
Height * [mm] 100 100
Weight** [kg] MIN. 21 - MAX 47 MIN. 24- MAX. 49
No. of leaves 1 2
MAX. leaf weight [kg] 110 70 +70
Passage opening (Vp) [mm] from 700 to 3000 from 800 to 3000
Beam length [mm] Vp x 2 +100 Vp x 2 +100
Maximum framed leaf thickness [mm] 60 60
Power supply voltage 230 V~ (+6% -10%) 50 Hz 230 V~(+6% -10%) 50Hz
MAX absorbed power [W] 140 140
Stand-by power without accessories [W] 3 3
Use frequency 100 % 100 %
Main motor (with encoder) powered at 36V powered at 36V
Max. accessories load (excluding SDK EVO) 1A, 24V 1A, 24V
Time/date backup battery Lithium CR2032 3V Lithium CR2032 3V
Motion backup battery NiMh 24V 1800mAh NiMh 24V 1800mAh
Traction by toothed belt by toothed belt
Opening/closing speed adjustment (empty) [cm/s] 10... 75 20... 150
Partial opening adjustment 5%... 95% of total opening 5%... 95% of total opening
Pause time adjustment [s] 0... 30 0... 30
Night pause time adjustment [s] 0... 240 0... 240
Anti-crushing safety device in opening/closing in opening/closing
Protection sensors monitoring (EN 16005:2012) can be bypassed can be bypassed
Energy Saving function can be enabled can be enabled
Low Energy movement can be enabled can be enabled
Operating ambient temperature [°C] -20... +55 -20... +55
Automation protection rating IP 23 (internal use) IP 23 (internal use)
* The dimensions and weight of the automation are specified excluding carriage and leaf overall dimensions, which are customisable
** For the specifications of weights in relation to the length of the automation, see 28.
