FaroArm® Quantum
August 2017
148
Chapter 7: Product Specifications
Quantum Rated Conditions
Operating Temperature Range 10°C to 40°C
50°F to 104°F
Storage Temperature Range -20°C to 70°C
-4°F to 122°F
Temperature Rate 3°C/5 min
5.4°F/5 min
Operating Humidity Minimum 0% RH, Maximum 95% RH
Storage Humidity Minimum 0% RH, Maximum 100% RH
Barometric Pressure Range Minimum
225.50 mmHG, 8.878 inHG
Maximum
825.07 mmHG, 32.483 inHG
Power Supply Universal worldwide voltage
100-240 VA C , 4 7 t o 6 3 Hz
Laser Line Probe Specifications and Accuracy
Accuracy ±25 μm (±.001 in)
Repeatability 25 μm, 2σ (.001 in)
Stand-off 115 mm (4.5 in)
Depth of Field 115 mm (4.5 in)
Effective Scan width Near Field 80 mm (3.1 in)
Far Field 150 mm (5.9 in)
Points per Line 2,000
Minimum Point Spacing 40 μm (.0015 in)
Scan Rate 280 frames/second
280 fps x 2,000 points/line = 560,000 points/
sec
Laser Class 2M
08m80e00_FaroArm_Quantum.book Page 148 Tuesday, August 22, 2017 11:03 AM
