FaroArm® Quantum
August 2017
152
Chapter 7: Product Specifications
All ScanArm values represent Maximum Permissible Error (MPE) in accordance
with ISO 10360-8 Annex D.
For more information, see “ISO 10360 Standard” on page 114.
Quantum
M
Accuracy
7-Axis
ISO 10360-12 Maximum
Permissible Error (MPE)
2.5 M length
Volumetric Accuracy (EUni)
Single Point Repeatability (SPAT)
PSize
PForm
LDia
0.042 mm (0.0017 in)
0.028 mm (0.0011 in)
0.020 mm (0.0008 in)
0.035 mm (0.0014 in)
0.060 mm (0.0024 in)
3.5 M length
Volumetric Accuracy (EUni)
Single Point Repeatability (SPAT)
PSize
PForm
LDia
0.085 mm (0.0033 in)
0.055 mm (0.0022 in)
0.040 mm (0.0016 in)
0.060 mm (0.0024 in)
0.110 mm (0.0043 in)
4.0 M length
Volumetric Accuracy (EUni)
Single Point Repeatability (SPAT)
PSize
PForm
LDia
0.100 mm (0.0039 in)
0.065 mm (0.0026 in)
0.040 mm (0.0016 in)
0.080 mm (0.0031 in)
0.132 mm (0.0052 in)
Quantum
M
7-Axis and Laser Line
Probe Accuracy (ScanArm)
Maximum Permissible Error
(MPE)
2.5 M length
Volumetric Accuracy (EUni) 0.063 mm (0.0025 in)
3.5 M length
Volumetric Accuracy (EUni) 0.100 mm (0.0039 in)
4.0 M length
Volumetric Accuracy (EUni) 0.115 mm (0.0045 in)
