 BYPASS: BYPASS Mode signal – Slave (Normally Open)
Output “ON” when a unit is in BYPASS mode on a Slave spindle of both a single system and
a multi system. This signal turns “OFF” when the unit is in RUN (ready to operate) mode.
 SPINDLE IN BYPASS: BYPASS Spindle Detected signal – Master (Normally Open)
For a Multi System (Master Spindle): Output “ON” when any of the connected spindles is in
BYPASS mode.
 SEQUENCE SELECTED BIT 0~4: Sequence Select Confirmation Bit (Binary coded)
 PARAMETER SELECTED BIT 0~4: Parameter Select Confirmation Bit (Binary coded)
Output confirmation of the SEQUENCE / PARAMETER SELECT 0~4 input selections.
These bits are active according to what sequence/parameter is set from the
sequence/parameter select inputs. Used to confirm proper selection before fastening starts.
For a Multi System (Master Spindle) the output will differ depending on the status of the
BANK SELECT signal:
If BANK SELECT is “OFF” outputs will reflect the Sequence Selected
If BANK SELECT is “ON” outputs will reflect the Parameter Selected
PAR/SEQ
SELECT BIT 4
Pin No. ：
：：
： 24
PAR/SEQ
SELECT BIT 3
Pin No. ：
：：
： 23
PAR/SEQ
SELECT BIT 2
Pin No. ：
：：
： 22
PAR/SEQ
SELECT BIT 1
Pin No. ：
：：
： 21
PAR/SEQ
SELECT BIT 0
Pin No. ：
：：
： 20
Parameter
(Sequence)
No.
OFF OFF OFF OFF OFF
1
OFF OFF OFF OFF ON
2
OFF OFF OFF ON OFF
3
OFF OFF OFF ON ON
4
OFF OFF ON OFF OFF
5
OFF OFF ON OFF ON
6
OFF OFF ON ON OFF
7
OFF OFF ON ON ON
8
OFF ON OFF OFF OFF
9
OFF ON OFF OFF ON
10
OFF ON OFF ON OFF
11
OFF ON OFF ON ON
12
OFF ON ON OFF OFF
13
OFF ON ON OFF ON
14
OFF ON ON ON OFF
15
OFF ON ON ON ON
16
ON OFF OFF OFF OFF
17
ON OFF OFF OFF ON
18
ON OFF OFF ON OFF
19
ON OFF OFF ON ON
20
ON OFF ON OFF OFF
21
ON OFF ON OFF ON
22
ON OFF ON ON OFF
23
ON OFF ON ON ON
24
ON ON OFF OFF OFF
25
ON ON OFF OFF ON
26
ON ON OFF ON OFF
27
ON ON OFF ON ON
28
ON ON ON OFF OFF
29
ON ON ON OFF ON
30
ON ON ON ON OFF
31
ON ON ON ON ON
32
