5-4 Compact Flash
Fastening results and fastening waveforms can be stored as files in a CompactFlash (CF) card
in the CF expansion unit. (hereinafter, “memory card”). The stored data can be read with any PC
containing a Compact Flash card reader.
･ If an unused memory card or a memory card used in another device is to
be used, be sure to format the card before using it. Please refer to
“Formatting the Memory Card” in the following section regarding the
formatting procedures.
･ Only the MASTER Axis of the multi system supports the memory card
storage function. This function is not available with the single system.
● Operation-Confirmed Memory Cards
Please select a memory card of 32GB or less as shown in the following table.
● Number of Storable Data Sets According to Capacity
･ Storage data format: Fastening results + Fastening waveform (180 degrees)
Approximately Number of Stored Data (Sets)
[Precautions Concerning Memory Card Usage]
･ Be careful as the data stored in the memory card may be erased under the
following conditions.
◆ When a user handles a memory card incorrectly.
◆ When a memory card is used or stored in an environment with static
electricity or electrical noise. TURN OFF POWER BEFORE INSTALLING
OR REMOVING CF CARD!
･ A memory card has a limited lifetime. The number of write cycles is limited
when using FLASH memory. The stored data may become unwriteable if the
card is used for a long period of time. Be sure to periodically back up the
necessary data in a PC.
･ Avoid use and storage in a location with sudden temperature change, a
location where condensation occurs, or a location exposed to direct sunlight.
･ Do not bend or apply a strong shocks to the memory card. Also, do not expose
the memory card to water or place it in a location of high temperature.
