FEC AFC3000 - Fieldbus Specifications

Chapter 2 Specifications
PAGE 2-6
● Anybus-CompactCom module unit list
Type Name Description Part No.
Anybus
CompactCom
Interface
modules
CC-Link-V2
For Expansion Unit 1
CC-Link V2 Interface
AB6211-B
DeviceNet
For Expansion Unit 1
DeviceNet Interface
AB6201-B
PROFIBUS DP-V1
For Expansion Unit 1
PROFIBUS DP-V1 Interface
AB6200-B
EtherNet-I/P
For Expansion Unit 1
EtherNet/IP Interface
AB6214-B
PROFINET
For Expansion Unit 1
PROFINET Interface
ABCC-PRT
AB6215-B
EtherCat
For Expansion Unit 1
EtherCat Interface
*Expansion Unit 1 with fieldbus base (Type ： MFC-FB) is required for any above modules
2-2-2 Fieldbus Specifications
Fieldbus
Name
I/O Input/Output Message Input/Output
MASTER Axis →
PLC
PLC → MASTER
Axis
MASTER Axis →PLC
PLC → MASTER
Axis
CC-Link
V1.10
14 bytes (112 points) 14 bytes (112 points)
32 bytes (16 words) 30 bytes (15 words)
CC-Link
V2.00
110 bytes (880
points)
110 bytes (880
points)
144 bytes (72 words) 142 bytes(71 words)
DeviceNet 32 bytes (256 points) 12 bytes (96 points)
2048 Ch. (4096 bytes) 16 Ch. (32 bytes)
PROFIBUS
DP-V1
32 bytes (256 points) 12 bytes (96 points)
2048 words (4096 bytes) 16 words (32 bytes)
EtherNet/IP
32 bytes (256 points) 12 bytes (96 points)
2048 words (4096 bytes) 16 words (32 bytes)
PROFINET
32 bytes (256 points) 12 bytes (96 points)
2048 Ch. (4096 bytes) 16Ch. (32 bytes)
EtherCat
32 bytes (256 points) 12 bytes (96 points)
2048 Ch. (4096 bytes) 16Ch. (32 bytes)
