Chapter 2 Specifications
PAGE 2-7
2-2-3 Tool Type
CFT - 201 RS1 – S x x
① ② ③ ④ ⑤
①Max. Torque ②Motor Capacity ③Tool Form ④ Connector Direction ⑤Option
Symbol
Max. TQ
(Nm)
Symbol Capacity Symbol Form Symbol Direction Symbol Specification
101
10
RS1 70W
S Straight
(Blank)
Straight
D
Double T/D
201 20 RS3 200W O Offset L Elbow H
High Speed
Seating
281 28
401
40
801 80
132
130
202 200
302 300
● Tool Type List
Tool
No.
Tool Type
Max.
Torque
[N
・
m]
Max. RPM
[rpm]
Min. RPM
[rpm]
Max. Rate
[N ・ m/deg]
Compatible
Unit Type
1 CFT-101RS1-S 10.00 3000
1
99.999 MFC-S024
2
CFT-201RS1-S 20.00 1293
1 99.999
MFC-S024
8 CFT-281RS1-S 28.00 992
1 99.999
MFC-S024
3 CFT-401RS1-S 40.00 712
1 99.999
MFC-S024
4 CFT-801RS3-S 80.00 1015 1
99.999
MFC-S060
5 CFT-132RS3-S 125.00 662 1
99.999
MFC-S060
6 CFT-202RS3-S 200.00 387 1
99.999
MFC-S060
7 CFT-302RS3-S
300.0
260 1
999.99 MFC-S060
NFT Type Tools (Added 9/2017)
Tool
No.
Tool Type
Max.
Torque
[N
・
m]
Max. RPM
[rpm]
Min. RPM
[rpm]
Compatible
Unit Type
100 NFT-502RM4-S 490.0 155
1
MFC-S120
101
NFT-802RM4-S 785.0 100
1
MFC-S120
125 NFT-051RM1-S1 4.90 500
1
MFC-S024
126 NFT-010RM1-S 0.98Nm 1100 1
MFC-S024
127 NFT-051RM1-S 4.90 1100
1
MFC-S024
129 NFT-101RM1-S1 9.80 500 1
MFC-S024
130 NFT-201RM1-S 19.60 500 1
MFC-S024
131 NFT-401RM1-S 39.20 250 1
MFC-S024
196 NFT-301RM2-A55
29.40 260 1 MFC-S024
183 NFT-401RH3-S
39.20 1980 1
MFC-S060
184 NFT-801RH3-S
80.00 1000 1
MFC-S060
211 NFT-122RH3-S
120.00 1000 1
MFC-S060
186 NFT-132RH3-S
130.00 580 1
MFC-S060
216 NFT-192RH3-S
190.00 625 1
MFC-S060
109 NFT-202RM3-S
196.00 222 1
MFC-S060
187 NFT-202RH3-S
200.00 408 1
MFC-S060
135 NFT-302RM3-S
294.0 150 1
MFC-S060
*The decimal point position of torque is same as [Max. Torque].
