Chapter 2 Specifications
PAGE 2-8
● Standard Spindle Assemblies
Spindle Assemblies are used to take up the travel of a threaded fastener as the fastener is rundown
(so the fastener does not run out of the socket or bit) This allows the tool to be advanced to the
fastener while the spindle assembly is compressed by the allowable stroke that is built in. As the
threaded fastener is rundown, the spindle will then follow the fastener as it is fastened.
SA
SASA
SA-
--
-3
33
3S1
S1S1
S1-
--
-2
22
2-
--
-38
3838
38-
--
-38
3838
38 x
x x
x X.XX
X.XXX.XX
X.XX
Straight Tools
Spindle Unit Type Standard Stroke Square Drive
Tool Size
SA-3S1-2-38-38 2” 3/8”
CFT-101RS1-S
CFT-201RS1-S
CFT-401RS1-S
SA-3S3-2-50-50 2” 1/2”
CFT-801RS3-S
CFT-132RS3-S
SA-3S3-2-62-62 2” 5/8” CFT-202RS3-S
SA-3S3-2-75-75 2” 3/4" CFT-302RS3-S
Offset Tools
Spindle Unit Type Standard Stroke Square Drive
Tool Size
OA-3S1-2-38-38 2” 3/8”
CFT-101RS1-O
CFT-201RS1-O
CFT-401RS1-O
OA-3S3-2-50-50 2” 1/2” CFT-801RS3-O
OA-3S3-2-62-62-132 2” 5/8” CFT-132RS3-O
OA-3S3-2-62-62 2” 5/8” CFT-202RS3-O
OA-3S3-2-75-75 2” 3/4" CFT-302RS3-O
IF SPINDLE IS
LONGER THAN
STANDARD
(INDICATES
OVERALL LENGTH
OF ROTOR ASSY)
VALUE A = X.XX
MALE OUTPUT
SQUARE DRIVE
38 = 3/8
50 = 1/2
62 = 5/8
75 = 3/4
FEMALE INPUT
SQUARE DRIVE
38 = 3/8
50 = 1/2
62 = 5/8
75 = 3/4
SPINDLE STROKE
(2,3 & 4in)
LEADING “3” = 3000 SERIES
S1,S3 = NUTRUNNER MOTOR
SIZE (SEE TOOL ASSEMBLY)
SA =STRAIGHT SPINDLE
OA =OFFSET SPINDLE
