FEC AFC3000 - System Parameter

Chapter 8 System Operation
PAGE 8- 37
[System Parameters – continued]
D-No. 304 Communication Speed
Setting range: 0 to 4 (CC-Link, DeviceNet)
The communication speed of the fieldbus set in the Unit is indicated.
Fieldbus Type
System Parameter D
-
No.304
0
1
2
3
4
CC-Link 156kbps 625kbps 2.5Mbps 5Mbps 10Mbps
DeviceNet 125kbps 250kbps 500kbps - -
D-No. 305 Occupied Stations
Setting range: 1 to 4 (CC-Link)
The number of occupied stations of the fieldbus set in the Unit is indicated.
D-No. 306 Extended Cyclic Setting
Setting range: 1, 2, 4, 8 (CC-Link)
The extended cyclic setting of the fieldbus set in the Unit is indicated.
D-No. 307 I/O Setting Byte Length “PLC ￫
￫￫
￫ MASTER Axis” [byte]
(besides standard IO and expansion IO)
The I/O setting byte length for “PLC ￫ MASTER Axis” of the fieldbus set in the Unit is indicated.
D-No. 308 I/O Setting Byte Length “Master Axis ￫
￫￫
￫ PLC” [byte]
(besides standard IO and expansion IO)
The I/O setting byte length for “MASTER Spindle ￫ PLC” of the fieldbus set in the Unit is indicated.
D-No. 309 Message Block Byte Length [byte]
(besides standard IO and expansion IO)
The message block byte length of the fieldbus set in the Controller is indicated.
Fieldbus type
CC
-
Link
DeviceNet
PROFIBUSDP
-
V1
PROFINET IO
EtherNet/IP
144byte 250 byte 64 byte 250 byte 250 byte
D-No. 310 Message Setting Byte Length “PLC ￫
￫￫
￫ MASTER Axis” [byte]
(besides standard IO and expansion IO)
The message setting byte length for “PLC ￫ MASTER Axis” of the fieldbus set in the Controller is
indicated.
D-No. 311 Message Setting Byte Length “Master Axis ￫
￫￫
￫ PLC” [byte]
(besides standard IO and expansion IO)
The message setting byte length for “MASTER Axis ￫ PLC” of the fieldbus set in the Controller is
indicated.
