Chapter 8 System Operation
PAGE 8- 36
[System Parameters – continued]
D-No. 300 Connected Fieldbus Information
The type of fieldbus installed in the (Fieldbus) Expansion Unit 1 is indicated.
D-No. 301 ANYBUS-Card Version (besides standard IO and expansion IO)
The ANYBUS-Card version installed in Expansion Unit 1 is indicated.
D-No. 302 Controller Setting Fieldbus Information
Secondary version type of fieldbus set in the controller (parameter) is indicated.
D-No. 303 Station No. (Node Address) (CC-Link, DeviceNet, PROFIBUSDP-V1)
The station No. (node address) of the fieldbus set in the Unit is indicated.
Fieldbus Type
CC
-
Link
DeviceNet
PROFIBUSDP
-
V1
1~64 0~63 0~125
Fieldbus not set
Expansion Unit 1 Uninstalled (Standard IO)
MFC
-
DT Installed
(Expansion IO)
MFC-CC Installed
(CC
-
Link)
MFC
-
DN Installed
(DeviceNet)
MFC-PB Installed
(PROFIBUS
DP
-
V1)
MFC-PN Installed
(PROFINET IO)
MFC-EN Installed
(EtherNet/IP)
CC-Link V1 CC-Link V2
