FEC AFC3000 - RS-232 C Fastening Result Output

Chapter 4 Installation and Wiring
PAGE 4-45
4-8-2 RS-232C Fastening Result Output Format (SINGLE system)
Fastening result data is output from the RS232C port on the front of the MFC Unit (configured as a
SINGLE system) in a fixed format when a fastening is completed. The data length of fastening result
data is 170bytes (170 letters, numbers or spaces) per fastening.
Format of output data is as follows: (Multi System data output shown after this data)
●Output Data Format (Torque decimal point is 2 digits, Rate decimal point is 3 digits)
Byte 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Item
STX
Date Time
ASCII
Hex
02H 32H 30H 31H 33H 2FH 30H 37H 2FH 31H 30H 31H 32H 3AH 33H 34H
DATA
2 0 1 3
／
0 7
／
1 0 1 2
：
3 4
Byte 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
Item
Time ID Data
ASCII
Hex
3AH 35H 36H 41H 42H 43H 44H 45H 46H 00H 3AH 35H 33H 33H 33H 31H
DATA
：
5 6 A B C D E
F
4
：
5
3 3 3
1
Byte 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48
Item
ID Data
ASCII
Hex
00H 00H 00H 00H 00H 00H 00H 00H 00H 00H 00H 00H 00H 00H 00H 00H
DATA
Byte 49 50 51 52 53 54 55 56 57 58 59
Item
ID Data Spindle No. PAR No. Spindle Judgment*
3
ASCII
Hex
00H 00H 00H 20H 31H 20H 32H 41H 43H 43H 20H
DATA
]
1
]
2 A C C
]
Byte
60 61 62 63 64
65 66 67 68 69 70 71 72 73 74 75
Item
Spindle Cycle Count Peak Torque *1 *2
ASCII
Hex
31H 32H 33H 34H 35H 36H 37H 38H 20H 31H 32H 2EH 33H 34H 20H 20H
DATA
1 2 3 4 5 6 7 8
]
1 2 . 3 4
] ]
Byte
76 77 78 79 80
81 82 83 84 85 86 87 88 89 90 91
Item
Final Torque *1 *2 SNUG Torque *1 *2
ASCII
Hex
20H 31H 32H 2EH 33H 34H 20H 20H 20H 31H 32H 2EH 33H 34H 20H 20H
DATA
]
1 2 . 3 4
] ] ]
1 2 . 3 4
] ]
