Chapter 4 Installation and Wiring
PAGE 4-22
4-4 Input Power Source Connections
Supply motor power to the AC 200-230V MOTOR POWER connector located on the lower right corner of the
unit.
The power source must be grounded. Also, do not install or use the grounding terminal
(FG) in common with a high-voltage circuit and be sure to provide a type 3 grou
solitarily.
PIN No.
(Recommended 16 AWG)
No.
(16 AWG Recom.)
No.
(16 AWG Recom.)
4 Red 5A Red 5B Red/Yellow
3 White 4A White 4B White/Yellow
2 Black 3A Black 3B Black/Yellow
1 Green (Frame Ground)
2A No Connection 2B No Connection
1A Green 1B Green/Yellow
MFC.
：
AMP
Type
：
D3200S Receptacle Housing
Model No.
：
1-178128-4 (Keying X)
Type
：
Receptacle Contact
(Pressure bonding type)
Model No.
：
1-175218-3
S024 / MFC
S024 / MFCS024 / MFC
S024 / MFC
4 U
UU
U
3 V
VV
V
2 W
WW
W
1
POWER
I/O
MOTOR
AC200V-230V
5A U
UU
U
4A V
VV
V
3A W
WW
W
2A
1A FG
FGFG
FG
3 Phase
AC Power
AC200
～
230V
MFC.
：
AMP
Type
：
D3200S Receptacle Housing
Model No.
：
1-178128-5 (Keying X)
Type
：
Receptacle Contact
(Pressure bonding type)
Model No.
：
1-175218-3
5B
4B
3B
2B
1B
3 Phase
AC Power
AC200
～
230V
