FEC AFC3000 - Offset Type

Chapter 4 Installation and Wiring
PAGE 4-14
4-2-2 Offset Type
● CFT-201RS1-O, CFT-401RS1-O
Tool Type
Max.
Torque
[Nm]
Max.
RPM
[rpm]
Min.
RPM
[rpm]
Mass
[kgf]
Square
Drive
[□mm]
Length
L
[mm]
A
[mm]
CFT-201RS1-O 20 1,293 1 2.3 9.5 332 302
CFT-401RS1-O 40 712 1 2.4 9.5 349 319
● CFT-801RS3-O
Tool Type
Max.
Torque
[Nm]
Max.
RPM
[rpm]
Min.
RPM
[rpm]
Mass
[kgf]
Square
Drive
[□mm]
CFT-801RS3-O 80 1,015 1 5.9 15.9
