FEC AFC3000 - Duty Cycle Calculation; Unit Identification; MFC Unit Type

Chapter 2 Specifications
PAGE 2-5
【
【【
【 Warning - Static Electricity 】
】】
】
・
・・
・ Due to the usage of many electronic parts
be careful not to expose the controller to
static electricity.
Keep in mind to discharge static electricity from th
e body by touching something
metal before touching an operation switch on the front panel.
2-1-4 Duty Cycle Calculation
Duty cycle is the ratio of tool fastening (running) time and idle time.
The duty cycle for AFC3000 Nutrunner System is calculated as below.
Duty Cycle （％）＝
（％）＝（％）＝
（％）＝ Fastening Time ÷ （
（（
（ Fastening Time ＋
＋＋
＋ Idle Time ）
））
） × 100
Maintain the duty cycle less than 60% under normal conditions.
An abnormal (A8-10 “Overload Error”) may occur if the unit is used in a condition that the duty cycle is
over 60%. (Additional abnormals may also be caused by high duty due to the higher current and heat
generated when the motor is ‘overworked’. (Make sure the motor surface temperature does not exceed
70°C (158°F) (Outer Motor Case)). Contact FEC regarding a specified cycle time more than 60% Duty.
2-2 Unit Identification
2-2-1 MFC Unit Type
Unit Type Name Description Part No.
Controller
AFC3000 24A Controller For Tool Type CFT-***RS1-* MFC-S024
AFC3000 60A Controller For Tool Type CFT-***RS3-* MFC-S060
AFC3000 120A Controller For RM4, RM5 Motors MFC-S120
Expansion
Unit
AFC3000-D-I/O Expansion Unit 1 with discrete I/O MFC-DT
AFC3000-FIELDBUS Expansion Unit 1 with no Fieldbus
*1
MFC-FB
AFC3000-CCLink-V2 Expansion Unit 1 with CC-Link V2 MFC-CC
AFC3000-DEVICENET Expansion Unit 1 with DeviceNet MFC-DN
AFC3000-PROFIBUSDP-V1 Expansion Unit 1 with Profibus MFC-PB
AFC3000-EtherNet-I/P Expansion Unit 1 with Ethernet-I/P I/O MFC-EN
AFC3000-PROFINET Expansion Unit 1 with Profinet I/O MFC-PN
AFC3000-EtherCat Expansion Unit 1 with EtherCat I/O MFC-EC
AFC3000-CF Expansion
Expansion Unit 2 with CompactFlash
Expansion RS232C Connector
MFC-CF
*1 ： Anybus-CompactCom module is NOT installed. (Requires Fieldbus specific board to operate)
*Anybus® is a registered trade mark of HMS Industrial Networks in Sweden, USA, and other countries.
