Chapter 8 System Operation
PAGE 8- 38
[System Parameters – continued]
D-No. 312 IP Address (upper 6 digits) D-No. 313 IP Address (lower 6 digits)
Setting range (each digit) : 0 to 255 (PROFINET IO, EtherNet/IP)
The IP address of the fieldbus set in the Controller is indicated.
D-No. 314 Subnet Mask (upper 6 digits) D-No. 315 Subnet Mask (lower 6 digits)
Setting range (each digit): 0 to 255 (PROFINET IO, EtherNet/IP)
The subnet mask of the fieldbus set in the Controller is indicated.
D-No. 316 Gateway (upper 6 digits) D-No. 317 Gateway (lower 6 digits)
Setting range (each digit): 0 to 255 (PROFINET IO, EtherNet/IP)
The gateway of the fieldbus set in the Controller is indicated.
D-No. 400 CF Card Storage Capacity [%]
The storable capacity of the CF card installed in the Expansion Unit 2 is indicated.
D-No. 401 Expansion RS232C-2 Communication Speed [bps]
The communication speed of the RS-232C-2 interface of the Expansion Unit 2 is indicated.
D-No. 402 Expansion RS232C-2 Parity
The parity of the RS-232C-2 interface of the Expansion Unit 2 is indicated.
D-No. 403 Expansion RS232C-2 Stop Bit [bit]
The stop bit of the RS-232C-2 interface of the Expansion Unit 2 is indicated.
D-No. 404 Expansion RS232C-2 Data Length [bit]
The data length of the RS-232C-2 interface of the Expansion Unit 2 is indicated.
D-No. 405 Expansion RS232C-3 Communication Speed [bps]
The communication speed of the RS-232C-3 interface of the Expansion Unit 2 is indicated.
D-No. 406 Expansion RS232C-3 Parity
The parity of the RS-232C-3 interface of the Expansion Unit 2 is indicated.
D-No. 407 Expansion RS232C-3 Stop Bit [bit]
The stop bit of the RS-232C-3 interface of the Expansion Unit 2 is indicated.
D-No. 408 Expansion RS232C-3 Data Length [bit]
The data length of the RS-232C-3 interface of the Expansion Unit 2 is indicated.
D-No. 500 Proface Display IP Address (upper 6 digits) D-No. 501 IP Address (lower 6 digits)
Setting range (each digit) : 0 to 255 (Ex. upper digit: 192.168) (Ex. lower digit: 11.200)
The ethernet IP address of a Proface remote display connected to the controller is set / indicated.
D-No. 502 Proface Display Language Select [bit]
Setting Range: None, 1 or 2
None: Disabled 1:Japanese 2:English
NOTE: Disable if Proface remote display is not being used. If turned on (“1” or “2”) the controller
will continue to ‘ping’ the Ethernet TCP/IP port attempting to connect to the Proface unit until
connection is made. This may be seen by monitoring devices on the Ethernet line as an
‘intrusion’ or ‘nuisance’.
