Chapter 8 System Operation
PAGE 8- 4
“◄” and “►” Pushbutton
Used to change modes (Fastening Result Mode, Set Value Mode, Real Time Mode and Status Mode)
when the system is in the RUN state.
Used for moving the cursor or changing the digit of the set value when the system is in the BYPASS
state.
“
◎
◎◎
◎
” SET Pushbutton
This push-button is used to set data and to confirm data setting changes when the system is in
BYPASS state.
“▲” and “▼” Pushbutton
These push-buttons are used for switching the display data or changing the set Data.
*The content of each display LED will be different based on the controller mode (RUN or BYPASS).
Refer to Page 8-5 ”RUN State” and Page 8-14 ”BYPASS State” for the display description in each mode.
