Chapter 8 System Operation
PAGE 8- 50
D-No.406
Reverse 1 Speed [rpm]
Setting Range
：
Tool’s minimum to maximum number of rotations.
Set the speed during the reverse operation.
This is the reverse speed used while the REV switch on the controller display unit is pressed.
When the D-No.110 [Reverse Torque High Limit] is exceeded during the reverse operation, the fastening
will stop and the abnormal signal A.9-8 [Reverse Torque Error] will be displayed.
D-No.407
Reverse 2 Speed [rpm]
Setting Range
：
Tool’s minimum to maximum number of rotations.
Set the speed during the reverse operation. Reverse 2 can be selected as a reverse option in any
internal sequence.
In a Single System. this is the speed used for D-No.002 [Fastening Option]
：
[Reverse Before Fastening]
When the D-No.110 [Reverse Torque High Limit] is exceeded during the reverse operation, the fastening
will stop and the abnormal signal A.9-8 [Reverse Torque Error] will be displayed.
D-No.408
Reverse 3 Speed [rpm]
Setting Range
：
Tool’s minimum to maximum number of rotations.
Set the speed during the reverse operation.
Reverse 3 can be selected as a reverse option in any internal sequence.
This is the speed used for D-No.005 [After Fastening Operation]
：
[1 Pulse Reverse].
When the D-No.110 [Reverse Torque High Limit] is exceeded during the reverse operation, the fastening
will stop and the abnormal signal A.9-8 [Reverse Torque Error] will be displayed.
D-No.409
Offset Check Speed [rpm]
Setting Range
：
Tool’s minimum to maximum speed.
Set the speed during the offset check operation.
